• 10938P-50

10938P-50

$39.38
Tax included

Circuitos integrados -IC

Última actualización

Datasheet10938P-50

V. F. Dot Matrix Display Controller

ROCKWELL

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Cascadable 20-character display driver expandable to 80 characters.
  • Utilizes a standard 5x7 character font.
  • Provides a separate output for cursor driver control.
  • Enables direct drive functionality for vacuum-fluorescent displays.
  • Incorporates a 128x35 PLA for segment decoding, allowing for the full 96-character ASCII set and 32 special characters.
  • Offers the choice of serial or parallel data input for both 8-bit display and control characters.
  • Available in a 40-pin DIP or 44-pin PLCC package.

Aplications

  • The MIC10938 and MIC10939 Dot Matrix Display Controller is a two-chip MOS/LSI general purpose display controller system designed to interface to dot matrix displays (vacuum fluorescent or LED).
  • The two-chip set will drive displays with up to 35 anodes (dots) and up to 20 grids (characters) plus a cursor. The chips can be cascaded to drive larger displays of as many as 80 characters.
  • An internal PLA-type decoder provides character decoding and dot pattern generation for the full 96-character ASCII set and an additional 32 special characters.

  • Brand
  • MPN
    10938P-50
