PM50RSE120

$144.38
Tax included

IGBT - IPM

Última actualización

DatasheetPM50RSE120

50A/1200V/7U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • a) Adopting new 4th generation planar IGBT chip, wich performance is improved by 1um fine rule process
  • For example, typical VCE(sat) = 1.7 V
  • b) Using new Diode wich is designed to get soft reverse recovery characteristics
  • 3 phase 50A, 600V current-sense IGBT for 15kHz switching
  • 15A, 600V Current-sense regenerative brake IGBT
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for overcurrent, short-circuit, over-temperature & under-voltage
  • Acoustic noise-less 3.7 kW class inverter application
  • UL Recognized Yellow Card No. E80276 (n)
  • File No. E80271

Aplications

  • Applications
  • General purpose inverter
  • servo drives
  • motor controls

  • Brand
  • MPN
    PM50RSE120
