• PM150CLA120

PM150CLA120

$551.25
Tax included

IGBT - IPM

Última actualización

DatasheetPM150CLA120

150A/1200V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • a) Adopting new 5th generation IGBT (CSTBT) chip, which performance is improeved by 1um fine rule process. For example, typical VCE(sat)=1.9V @ Tj=125 C
  • b) I adopt the over-temperature conservation by Tj detection of CSTBR chip, and error output is possible from all each conservation upper and lower arm of IPM.
  • 3o/ 150A, 1200V Current-sense IGBT type inverter
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for, short-circuit, over-temperature & under-voltage (P-Fo available from upper arm devices)
  • Acoustic noise-less 30kW class inverter application
  • UL Recognized Yellow Card No. E80276(N)
  • Fle No.E80271

Aplications

  • Applications
  • General purpose inverter
  • Servo drives
  • motor controls

  • MPN
    PM150CLA120
