• A4504

A4504

$4.00
Tax included

VARIOS

Última actualización

DatasheetA4504

8mA/30V/8 PIN

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • High CMR, High Speed Optocouplers
  • Short Propagation Delay for TTL and IPM
  • 15kV/us Minimum Common Mode Transient
  • Immunity at VCM = 1500 V for TTL/Load at
  • Drive
  • High CTR at T a = 25u00c2u00b0C :
  • >25% for HCPL-4504/0454
  • >23% for HCNW4504
  • Electrical Specifications for Common IPM
  • Applications
  • TTL Compatible
  • Guaranteed Performance from 0u00c2u00b0C to 70u00c2u00b0C
  • Open Collector Output
  • Safety Approval :
  • UL Recognized - 2500 Vrms for 1 minute for
  • HCPL-4504#020 and HCNW4504) per UL 1577
  • CSA Approved
  • VDE 0884 Approved
  • BSI Certified (HCNW4504)

Aplications

  • Applications
  • Inverter Circuits and Intelligent
  • Power Module (IPM) interfacing
  • High Common Mode Transient
  • Immunity (> 10kV/us for an IPM
  • load/drive and (tpLH - tpHL
  • Line Receivers
  • Replaces Pulse Transformers

  • MPN
    A4504
