• MC68681P

MC68681P

$7.88
Tax included

VARIOS

Última actualización

DatasheetMC68681P

150mA/5V/1U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Dual Asynchronous Reciiver/Transmitter IC
  • M6800 Bus Compatible
  • Two, Independent, Full-Duplex Asynchronous
  • Receiver/Transmitter Channes
  • Maximum Data Transfer
  • 1X - 1 Mbps
  • 16X - 125 kbps
  • Quadruple-Buffered Receiver Data Registers
  • Double-Buffered Transmitter Data Registers
  • Independently Programmable Baud Rate for
  • Each Receiver and Transmitter
  • Selectable from :
  • 18 Fixed Rates : 50 to 38.4k Baud
  • One User-Defined Rate Derived from a
  • Programmable Timer/Counter
  • External 1X Clock or 16X Clock
  • Programmable Data Format
  • Five to Eight Data Bits plus Parity
  • Odd, Even, No Parity, or Force Parity
  • One, One and One-Half, or Two Stop Bits
  • Programmable in One-Sixteenth-bit Increments
  • Programmable Channel Modes
  • Normal (Full Duplex)
  • Automatic Echo
  • Local Loopback
  • Remote Loopback
  • Automatic Wakeup Mode for Multidrop Applications
  • Multifunction 6-Bit Input Port
  • Can Serve as Clock or Control Inputs
  • Charge-of-State Detection on Four Inputs
  • Multifunction 8-Bit Output Port
  • Individual Bit Set/Reset Capability
  • Outputs Can Be Programmable To Be Status/Interrup
  • Signals
  • Multifuntion 16-Bit Programmable Counter/Timer
  • Versatile Interrupt System
  • Single Interrupt Output with Maskable Interrpting
  • Conditions
  • Interrupt Vector Output on Interrup Acknowledge
  • Output Port Can Be Configured To Provide a Total
  • of up to Six Separate Wire-ORable Interrupt Outputs
  • Parity, Framing, and Overrun Error Detection
  • False-start Bit Detection
  • Line-Break detection and Generation
  • Detects Break Originating in the Middle of a Character
  • Start-End Break Interrupt/Status
  • On-Chip Crystal Oscillator
  • TTL Compatible
  • Single +5 - V Power Supply

Aplications

  • Semiconductors High Power Equipment Repair

  • MPN
    MC68681P
