• PM50RLB060

PM50RLB060

$110.46
Tax included

IGBT - IPM

Última actualización

DatasheetPM50RLB060

50A/600V/7U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • a) Adopting new 5th generation IGBT (CSTBT) chp,
  • which performance is improved by 1um fine
  • rule process.
  • For example, typical VCE(sat)=1.5V @ Tj125u00c2u00b0C
  • b ) I adopt the over-temperature conservation by
  • Tj detection of CSTBT chip, and error output is
  • possible from all each conservation upper and lower
  • arm of IPM
  • c ) New small package
  • Reduce the package size by 32%, thickness by 22%
  • from S-DASH series
  • d ) Current rating of brake part increased
  • 60% for the current rating of inverter part
  • 3 o/ 50A, 600V Current-sense IGBT type inverter
  • 30A, 600V Current-sense regenerative brake IGBT
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for,
  • short-circuit, over-temperature & under-voltage (
  • P-Fo available from upper arm devices)
  • Acoustic noise less 3.7kW class inverter application

Aplications

  • Applications
  • General purpose inverter
  • servo drives
  • motor controls

  • MPN
    PM50RLB060
