• SP721AP

SP721AP

$10.74
Tax included

VARIOS

Última actualización

DatasheetSP721AP

20nA/30V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Electronic Protection Array for ESD and Overvoltage Protection
  • ESD Interface Capability for HBM Standars
  • MIL STD 3015.7u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6.15kV
  • IEC 61000-4-2, Direct Discharge,
  • Single Input u00e2u0080u00a6u00e2u0080u00a6u00e2u0080u00a6..4kV (Level 2)
  • Two Inputs in Parallel u00e2u0080u00a6u00e2u0080u00a6..8kV (Level 4)
  • IEC 61000-4-2, Air Discharge ..........15kV (Level 4)
  • High Peak Current Capability
  • IEC 61000-4-5 (8/20us)........+-3A
  • Single Pulse, 100us Pulse width ......+-2A
  • Single Pulse, 4us Pulse Width ..........+-5A
  • Designed to Provide Over-Voltage Protection
  • Single-Ended Voltage Range to ............+30V
  • Differential Voltage Range to ...............+-15V
  • Fast Switching ............. 2ns Rise Time
  • Low Input Leakages ......1nA at 25u00c2u00b0C Typical
  • Low Input Capacitance ....... 3pF Typical
  • An Array of 6 SCR/Diode Pairs
  • Operating Temperature Range .......-40u00c2u00b0C to 105u00c2u00b0C

Aplications

  • Applications
  • Microprocessor/Logic Input
  • Protection
  • Data Bus Protection
  • Analog Device Input Protection
  • Voltage Clamp

  • MPN
    SP721AP
