• PM100RLA120

PM100RLA120

$530.25
Tax included

IGBT - IPM

Última actualización

DatasheetPM100RLA120

100A/1200V/7U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • Adopting new 4th generation planar IGBT (CSTBT) chip, which performance is improved by 1um fine rule process. For example, typical VCE(sat)=1.9V @ Tj = 125u00c2u00b0C
  • I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM
  • Current rating of brake part increased
  • 50% for the current rating of inverter part
  • 3 phase 100A, 1200V Current-sense IGBT type inverter
  • 50A, 1200V Current-sense regenerative brake IGBT
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for over-current, short-circuit, over-temperature &
  • under-voltage (P-Fo available from upper arm devices)
  • Acoustic noise-less 18.5kW/22kW class inverter application
  • UL Recognized Yellow Card No. E80276(N)
  • File No. E80271

Aplications

  • Applications
  • General purpose Inverter
  • Servo drives
  • Motor control

  • Brand
  • MPN
    PM100RLA120
