• TB6560AHQ

TB6560AHQ

$15.78
Tax included

VARIOS

Última actualización

DatasheetTB6560AHQ

3.5A/6V/1U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • PWM Chopper-Type Bipolar Driver IC
  • for Stepping Motor Control
  • Single-chip motor driver sinusoidal microstep
  • control of stepping motors
  • High output withstand voltage due to the use of
  • BiCD process :
  • Ron (upper and lower sum) =
  • TB6560AHQ : 0.6 Ohms (typ.)
  • TB6560AFG : 0.7 Ohms (tip.)
  • Forward and reverse rotation
  • Selectable phase excitation modes (2,
  • 1-2, 2W1-2 and 4W1-2)
  • High output withstand voltage : VDSS = 40 V
  • High output current : IOUT =
  • TB6560AHQ : 3.5 A (peak)
  • TB6560AFG : 2.5 A (peak)
  • Package :
  • HZIP25-1.27
  • HQFP64-P-1010-0.50
  • Internal pull-down resistor on inputs :
  • 100 kOhms(typ.)
  • Output monitor pin : Mo current (IMO (max)
  • = 1 mA)
  • Reset and enable pins
  • Thermal shutdown (TSD)

Aplications

  • Semiconductors High Power Equipment Repair

  • Brand
  • MPN
    TB6560AHQ
