84870403

$623.30
Tax included

RELEVADOR DE ESTADO SOLIDO

Última actualización

Datasheet84870403

L2N 120 V AC 11-pin

CROUZET

Delivery time : 1-2 semanas.

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Supply voltage Un 230 V, 110 V, 48 V, 24 V AC, 50/60 Hz
  • Operating range 0,85 ?1,15 x Un
  • Max. absorbed power 3 VA
  • Adjustable sensitivity 5 k??100 k?
  • Measurement accuracy (at maximum sensitivity) 0 ?+30 %
  • Electrode voltage (max) 24 V AC (50/60 Hz)
  • Electrode current (maximum) 1 mA (50/60 Hz)
  • Maximum cable capacity 10 nF
  • Response time high level 300 ms
  • Response time low level 500 ms
  • Output relay (according to AC1 resistive load) 1 AgCdO switch 8 A AC max.
  • Galvanic isolation via transformer (4 kV, 8 mm creepage
  • distance) Class II
  • Isolation of contacts and electrodes from power supply 2,5 kV AC
  • Temperature limits use (°C) -20 ?+60
  • Temperature limits stored (°C) -30 ?+70
  • Weight (g) 140

Aplications

  • Relay for controlling level of conductive liquids
  • Output relay status display LED
  • Sensitivity adjustable from 5 k? to 100 k?
  • LN
  • Relay for controlling level of conductive liquids
  • Regulation of two levels : minimum, maximum
  • Empty function
  • Plug in (8 or 11 pins)
  • Sensitivity adjustable from 5 k? to 100 k?
  • LN2
  • Combined fill and empty functions
  • Combined regulation of pumping out a well and filling a tank
  • Plug in (11 pins)
