• MIG50J901H

MIG50J901H

$81.38
Tax included

IGBT - IPM

Última actualización

DatasheetMIG50J901H

50A/600V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTEGRATED GTR MODULE
  • Integrates Inverter, Converter and Brake Power Circuits in One Package
  • Output (Inverter Stage) :
  • 3 o/ 50A / 600V High Speed type IGBT
  • VCE(sat) = 4.00 V (Max.)
  • tf = 0.30us (Max.)
  • trr = 0.15us (Max.)
  • Input (Converter Stage)
  • 3 o/ 30A / 800 V Silicon Rectifier
  • VF = 1.20 V (Max.)
  • Brake Stage :
  • 25 A / 600V IGBT & 15A / 600V FRD
  • The Electrodes are Isolated from Case

Aplications

  • Applications
  • High Power Switching
  • Motor Control

  • Brand
  • MPN
    MIG50J901H
