• SKM75GB063D

SKM75GB063D

$57.75
IVA incluido

MODULOS IGBT

Última actualización

DatasheetSKM75GB063D

75A/600V/1U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Super NPT-IGBT Module
  • N channel, homogeneous Si-structure (NPT-Non punch-through IGBT)
  • Low tail current with low temperature dependence
  • High short circuit capability, self limiting if term. G is clamped to E
  • Pos. Temp.-coeff. Of VCEsat
  • Very low Cies, Coes, Cres
  • Latch-up free
  • Fast & soft inverse CAL diodes
  • Isolated copper baseplate using DBC Direct Copper Bonding Technology without hard mould
  • Large clearance (10 mm) and creepage distances (20 mm)

Aplications

  • Applications
  • Switching (not for linear use)
  • Switched mode power supplies
  • Three phase inverters for servo / AC motor speed control
  • Pulse frequencies also > 10 kHz

  • Marca
  • Nº Pieza fabricante (NPM)
    SKM75GB063D
