• 84137120
  • 84137120

84137120

$84.16
IVA incluido

RELEVADOR DE ESTADO SOLIDO

Última actualización

Datasheet84137120

48-660VAC 50A / CONTROL 3-32VDC

CRYDOM

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Product: Solid State Relays
  • Type: Indicator
  • Mounting Style: Panel Mount
  • Load Current Rating: 50 A
  • Load Voltage Rating: 48 VAC to 660 VAC
  • Relay Contact Form: 1 Form A (SPST-NO)
  • Output Type: Triac
  • Control Voltage Range: 3 VDC to 32 VDC
  • Input Current: 10 mA to 15 mA
  • IP Rating: IP20
  • Series: GN
  • Length: 57.3 mm
  • Width: 44.5 mm
  • Height: 30.9 mm

Aplications

  • These powerful VAC output SSRs have superior thermal performance thanks to the use of DBC technology and are available in IP20 or IP00 protection degree packages. These new generation Panel Mount solid state relays all feature anti-rotation barriers, flexible control voltage options, LED input status indicator, and a wide range of power ratings to make your product selection easier.

Crouzet Solid State Relays, GN Series

Crouzet

84137120

SOLID STATE RELAY, 50A, 575VAC, IP20 CONTROL: 3-32VDC, LOAD: 48-660VAC IP20 CASE, ZERO CROSSING ; No. of Circuits; 1

Switching Type; Zero Voltage

Amps; 50

Circuit; 1-NO

Input Polarity; DC

Input Signal; 3~32 VDC

Output Voltage; 48~660 VAC

Mounting; Panel

Output Type; SCR AC Switch

Termination; Screw Terminals

Status Ind.; Yes

Transient Overvoltage; 1200 Volts ;

  • Nº Pieza fabricante (NPM)
    84137120
