• PM50CLB060

PM50CLB060

$118.35
IVA incluido

IGBT - IPM

Última actualización

DatasheetPM50CLB060

50A/600V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • a) Adopting new 5TH generation IGBT (CSTBT) chip,
  • which performance is improved by 1um fine
  • rule process.
  • For example, typical VCE(sat)=1.5V @ Tj125u00c2u00b0C
  • b ) I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error outputs is possible from all each conservation upper and lower arm of IPM
  • c) New small package
  • 3 phase 50A, 600V Current-sense IGBT type inverter
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for, short circuit, over-temperature
  • under-voltage (P-Fo available from upper arm devices)
  • Acoustic noise-less 3.7kW class inverter applications

Aplications

  • Applications
  • General purpose inverter
  • servo drives
  • motorcontrols

  • Nº Pieza fabricante (NPM)
    PM50CLB060
