• PM300CLA120

PM300CLA120

$1,117.75
IVA incluido

IGBT - IPM

Última actualización

DatasheetPM300CLA120

300A/1200V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • a) Adopting new 5Tth generation IGBT (CSTBT) chp, which performance is improved by 1um fine rule process. For example, typical VCE(sat) =1.0V @ Tj=125 C
  • b) I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM
  • 3 0/ 300A, 1200V Current-sense IGBT type inverter
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for, short-circuit. over-temperature & under-voltage (Fo available from all arm devices)
  • Acoustic noise-less 45kW/55kW class inverter applications
  • UL Recognized Yellow Card No. E80276(n)
  • File No. E80271

Aplications

  • Applications
  • General purpose inverter
  • servo drives
  • motor controls

  • Nº Pieza fabricante (NPM)
    PM300CLA120
