• SKD75GAL123D16L12

SKD75GAL123D16L12

$312.38
IVA incluido

MODULOS RECTIFICADOR PUENTE TRIFASICO

Última actualización

DatasheetSKD75GAL123D16L12

100A/1200V/7U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Input Bridge B6U with brake chopper MODULE
  • Round main terminals (2 mm o/)
  • Easy drilling of PCB
  • Input diodes glass passivated
  • 1400 V PIV, good for 500 VAC
  • High I2t rating (inrush current)
  • IGBT is latch-up free, homogeneous NPT silicon-structure
  • High short circuit capability, self limiting to 6 Icnom
  • Fast & soft CAL diodes
  • Isolated copper baseplate using DCB Direct Copper Bonding Technology
  • Large clearance (9 mm) and creepage distances
  • (13 mm)

Aplications

  • Applications
  • Input rectifier bridge
  • (B6U) with brake chopper
  • for PWM inverter drives
  • using SEMITRANS
  • SKM 75GD123D

  • Nº Pieza fabricante (NPM)
    SKD75GAL123D16L12
