EL63D10Z5/28P10X6MR

$609.50
IVA incluido

ENCODER / RESOLVER

Última actualización

DatasheetEL63D10Z5/28P10X6MR

5- 25VDC

ELTRA

Delivery time : 1-2 semanas.

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Principle of operationincremental
  • Shaft typesolid shaft
  • Mounting typecentering square flange
  • Electronic interfacepush pull
  • Resolution, ppr10
  • Zero pulse+
  • Power supply, V DC5…28
  • Shaft diameter, mm10
  • Enclosure ratingIP54
  • Max Rotation speed, rpm6000
  • Output typeMIL connector
  • Direction typeradial
  • Construction size (diam.), mm63
  • Max output frequency250 kHz
  • Operating temperature , °C-10…+60
  • Operating temperature , °F+14…+140
  • Measurement typerotary
  • Type of sensoroptical
  • Weight, g350

Aplications

  • With solid shaft.
  • Mounting by centering square flange 31,75 mm diam.
  • PUSH-PULL electrical interface. Due to complementary transistor it is possible to use encoder with longer cable connections and optimal data trasmission even at high working speed.
  • With zero pulse.
  • 10 mm shaft encoder (diameter).
  • High resistant encoder for standard industrial applications.
  • 200 N shaft load.

  • Referencia
    EL63D10Z5/28P10X6MR
  • Nº Pieza fabricante (NPM)
    EL63D10Z5/28P10X6MR
