PM300CLA060

Name: PM300CLA060
Brand: No Identificado
SKU: 2090
Price: 472.5 USD
Availability: OutOfStock

$472.50

IVA incluido

IGBT - IPM

Última actualización 2021-12-16 14:51:29

300A/600V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

Security policy

Tus compras son seguras

Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

INTELLIENT POWER MODULE
a ) Adopting 5th generation IGBT (CSTBT) chips, which performance
is improved by 1um fine rule process
For example, typical Vce(sat) = 1.5 V @ Tj = 125u00c2u00b0C
b )I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from each conservation upper and lower arm of IPM
3 phase 300A, 600V Current-sense IGBT type inverter
Monolithic gate drive & protection logic
Detection, protection & status indication circuits for
over-current, short-circuit, over-temperature & under-voltage (P-Fo available from upper arm devices)
Acoustic noise-less 30kW class inverter applications
