• PM150RSD120

PM150RSD120

$551.25
IVA incluido

IGBT - IPM

Última actualización

DatasheetPM150RSD120

150A/1200V/7U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • Adopting new 4th generation planar IGBT chip, which performance is improved by 1um fine rule process.
  • Using new Diode which is designed to get soft reverse recovery characteristics
  • 3 phase 150A, 1200V Current-sense IGBT for 15kHz switching
  • 50A, 1200V Current-sense regenerative brake IGBT
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for over-current, short-circuit, over-temperature &
  • under-voltage (P-Fo available from upper leg devices)
  • Acoustic noise-less 30kW class inverter application
  • UL Recognized Yellow Card No. E80276(N)
  • File No. E80271

Aplications

  • Applications
  • General purpose Inverter
  • Servo drives
  • Motor control

  • Marca
  • Nº Pieza fabricante (NPM)
    PM150RSD120
