W2S130-AA03-90

$115.00
IVA incluido

Ventiladores

Última actualización

DatasheetW2S130-AA03-90

115V-230V/30-40W/3200 RPM

EBM-PAPST

Delivery time : 1-2 semanas.

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Mass 1.1 kg
  • Size 130 mm
  • Surface of rotor Rotor open, coated in black
  • Material of impeller Sheet steel, coated in black
  • Material of wall ring Die-cast aluminium, coated in black
  • Number of blades 7
  • Direction of air flow V
  • Direction of rotation Counter-clockwise, seen on rotor
  • Type of protection IP 20
  • Insulation class B
  • Max. permissible ambient motor
  • temp. (transp./ storage)
  • + 80 °C
  • Min. permissible ambient motor
  • temp. (transp./storage)
  • - 40 °C
  • Mounting position Any
  • Condensate discharge holes None
  • Operation mode S1
  • Motor bearing Ball bearing
  • Speed steps Dual voltage

Aplications

  • Type W2S130-AA03-90
  • Motor M2S052-CA
  • Phase 1~ 1~ 1~ 1~
  • Nominal voltage VAC 115 115 230 230
  • Frequency Hz 50 60 50 60

  • Nº Pieza fabricante (NPM)
    W2S130-AA03-90
