84871122

$315.00
IVA incluido

RELEVADORES

Última actualización

Datasheet84871122

2-20 A, 24-240 VAC/DC

CROUZET

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • Timing
  • Delay on threshold crossing (Tt) 0.1 ? 10 s (0, +10 %)
  • Repetition accuracy with constant parameters
  • (according to IEC/EN 60255-1)
  • ± 3 %
  • Power ON delay ? 650 ms
  • Reset time max 1500 ms
  • Delays on power up (Ti) 200 ms
  • Supply
  • Voltage type for actuating AC/DC
  • Rated control supply voltage Un at AC 24 ? 240 V
  • AC supply voltage frequency 50/60HZ ± 10 %
  • Voltage supply tolerance -15 % / +10 %
  • Operating range 20.4 ? 264 Vz
  • Polarity with DC voltage Yes
  • Galvanic isolation of power supply/Input circuit Yes
  • Galvanic isolation of power supply/Output circuit Yes
  • Galvanic isolation of Input circuit/Output circuit Yes
  • Immunity from micro power cuts: typical 10 ms
  • Maximum Power consumption at Un AC: 3.5 VA
  • DC: 1 W

Aplications

  • Current Monitoring Relay MIC, Single-Phase, Measuring Range 2-20 A, 24-240 VAC/DC, 1 C/O, 5 A, DIN Rail, 17.5 mm

  • Nº Pieza fabricante (NPM)
    84871122
