• PM300CBS060

PM300CBS060

$618.05
IVA incluido

IGBT - IPM

Última actualización

DatasheetPM300CBS060

300A/600V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIENT POWER MODULE
  • a ) Adopting 4th generation IGBT chips, which performance
  • is improved by 1um fine rule process
  • For example, typical Vce(sat) = 1.7 V
  • b ) Using new Diode which is designed to get soft
  • reverse recovery characteristics
  • c ) Over-temperature protection by detecting Tj of the
  • IGBT chips
  • 3 o/ 300A, 600V Current-sense IGBT type inverter
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for
  • over-current, short-circuit, over-temperature & under-
  • voltage
  • Acoustic noise-less 30kW class inverter applications

Aplications

  • Applications
  • Servo drives
  • motor controls

  • Marca
  • Nº Pieza fabricante (NPM)
    PM300CBS060
