• SIM6822M

SIM6822M

$31.56
IVA incluido

VARIOS

Última actualización

DatasheetSIM6822M

5A/600V/1U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • High Voltage 3-phase Motor Driver
  • Built-in Bootstrap Diodes with Current Limiting Resistors (60 Ohms)
  • CMOS-compatible Input (3.3 V or 5 V)
  • Bare Lead Frame : Pb-free (RoSH Compliant)
  • Isolation Voltage : 1500V V (for 1 min)
  • UL-recognized Component (File No. E118037) (SIM6880M UL Reconition Pending)
  • Fault Signal Output at Protection Activation (FO Pin)
  • High-side Shutdown Signal Input (SD Pin)
  • Protections Include :
  • Overcurrent Limit (OCL): Auto-reset
  • Overcurrent Protection (OCP): Auto-reset
  • Undervoltage Lockout for Power Supply
  • High-side (UVLO_VB) : Auto-restart
  • Low-side (UVLO_Vcc) : Auto-restart
  • Thermal Shutdown (TSD) : Ato-restart
  • Each half-bridge circuits of a pre-driver circuit that is completely independent from the others
  • Protection against simultaneous high and low-side tuming on
  • Bootstrap diodes with series resistors for suppresing i

Aplications

  • Applications
  • For motor drives as :
  • Refrigerator Compressor Motor
  • Fan Motor and Pump Motor for Washer and Dryer
  • Fan Motor for Air Conditioner, Air Purifier, and Electric Fan

  • Marca
  • Nº Pieza fabricante (NPM)
    SIM6822M
