PM75RLB060

$144.38
IVA incluido

IGBT - IPM

Última actualización

DatasheetPM75RLB060

75A/600V/6U

No Identificado

Delivery time :

Agotado

Interested in this product? Drop us an email and we will let you know when it's available for order.

  Security policy

Tus compras son seguras

  Delivery policy

Envíos gratuitos en compras mayores a 160USD sin iva. La entrega depende de la disponibilidad.

  Return policy

Todos nuestros productos cuentan con una garantía contra defectos de fabricación.

Features

  • INTELLIGENT POWER MODULE
  • a) Adopting new 5th generation IGBT (CSTBT) chip, which performance is improved by 1 um fine rulr process. Foe example, typical VCE(sat) = 1.5 V @ Tj = 125 C
  • b) I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM
  • c) New small package
  • Reduce the package size by 32 %, thickness by 22% from S-DASH series
  • d) Current rating of brake part increased
  • 67 % for the current rating of inverter part
  • 3-phase 75 A, 600 V Current-sense IGBT type inverter
  • 50 A, 600 V Current -sense IGBT type inverter
  • Monolithic gate drive & protection logic
  • Detection, protection & status indication circuits for, short-circuit, over-temperature & under-voltage (P-Fo available from upper arm devices)
  • Acoustic noise-less 5.5 kW/7.5kW class inverter application

Aplications

  • Applications
  • General porpose inverter
  • servo drives
  • motor control

  • Marca
  • Nº Pieza fabricante (NPM)
    PM75RLB060
